V I C-tor-e-News
...a quarterly newsletter from V.I.C. Leak Detection
Volume 1, Issue 13, Summer 2011
U n p a r a l l e l e d A p p l i c a t i o n S u p p o r t
In This Issue...
► VTE 2011 & AE Expo
► Medical Device Application
► NASA Space Application
► Li-Ion Leak Test Application
► New-Touch Panel GUI Display
► New-Service and Rental Plan
► New-Air Leak Test Product
► New-H2 Sniffer
► Helium Recovery
► Calibrated Gas Leaks
► Upcoming Events
V. I. C. Web Links
Greetings
V.I.C. Products Featured at Vacuum Tech Expo 2011
St. Petersburg, Russia—April 13—15, Intech Analytics Russian distributor/representative and general sponsor of VTE 2011 features V.I.C. helium leak detector held at Eco Centre Sokolniki, Moscow, Russia.
The exhibition was supported by: the Government of Moscow, the Moscow Committee on Science and Technology, the Moscow Chamber of Commerce and Industry, the Moscow State Technical University n.a. N.E.Bauman.
Analytic Expo 2011
Crocus Expo International Exhibition Center, Moscow, Russia—April 26—29, 2011.
Exhibit included analytical equipment, control and measuring devices, nanotechnologies, nanomaterials and bioanalytics. Professionals related to the field of chemical/petrochemical, pharmaceuticals/cosmetics, medicine/diagnostics, environment, electrical engineering/electronics attended the event.
Featured product at both events included the high performance, high sensitivity MS-40 portable helium leak detector—fully automatic, easy to use, and highly accurate—this advanced design leak detector is ideal for a broad range of applications—from medical to food and beverage packaging. More
Medical Device Testing Application for Helium
The V.I.C. MS-40 was selected to test an implantable device used as a Ventricular Assist System in patients with a weakened heart.
The HeartWare HVAD® pump is designed to help a patient's weakened heart pump blood throughout his or her body by removing blood from the left side of the heart and pumping the blood into the aorta (the large blood vessel that carries blood from the heart to the rest of the body).
Using the V.I.C. MS-40 the two pump halves are tested individually to ensure there are no leaks. Once the pump is assembled, the HVAD is tested as a working unit with a leak rate specification of 1.8^-8 atm cc/sec.
The MS-40 will allow the manufacturer to test for leaks in medical devices as small as 4x10^-11 atm cc/sec. The unit senses leaks by nondestructively introducing device to a vacuum and utilizing specially tuned mass spectrometer to detect even the smallest amount of Helium leakage.
The MS-40 is high performance, high sensitivity portable helium leak detector which can be used for testing the hermeticity of implantables as well as a host of other medical devices. More on the MS-40
HeartWare and HVAD are registered trademarks of HeartWare International, Inc.
The MS-50 Dry utilized for Space Applications
NASA Glenn Research Center (GRC) in Cleveland, OH is developing advanced space-rated vacuum seals in support of future space exploration missions. These seals must have extremely low leak rates to ensure that astronauts have sufficient breathable air for missions to the International Space Station or the Moon.
NASA GRC is performing leak tests on candidate seal
designs using the MS-50 Dry helium leak detector to demonstrate that the seals satisfy stringent leak rate requirements.
This MS-50 Dry was selected because it is capable of accurate and repeatable gross leak testing at levels up to 1x10^-2 atm-cc/sec.
More on space/aerospace applications
Automotive Lithium-Ion Battery Leak Testing Systems
There are many reasons why more and more people are looking into fuel-efficient, cleaner-running cars–from soaring gas prices to global warming–hence the need for an alternate power source.
Li-Ion batteries have the greatest charge capacity over competing battery technologies, thus the demand to incorporate them into today's extended range electric cars.
V.I.C. is able to provide a High Speed Fully Automatic Helium Leak Test Systems to test the hermeticity of Li-Ion Batteries used in hybrid and all electric vehicle applications.
V.I.C. will continue to provide automotive lithium-ion battery manufacturers leak test equipment that will be the solution to their unique testing specifications. More Applications
Portable Helium Leak Detectors Sport New Touch-Panel GUI Display
Vacuum Instrument Corp. introduces a new series of helium mass spectrometer leak detectors with Touch-Screen GUIs for testing the integrity of vacuum systems, and parts using helium leak detection techniques.
The Touch-Screen GUI allows for greater system control and monitoring during system start-up and operation. More Details
Proudly Made in the U.S.A.
New -- Service & Rental Plan
Vacuum Instrument Corp. announces new services and rental plan. V.I.C. will be offering a variety of leak-testing services for helium/air leak detection requirements, as well as new support programs. More Details
VIC-TORR TM -- Mass Flow, Pressure/Vacuum Decay System
VIC-Torr is a high resolution test instrument that can be configured as a
Mass Flow, Pressure Decay or Vacuum Decay leak tester and is available in single or multi-channel versions. The robust color LCD touch screen makes it easy for the operator to determine if a test product is pass/fail. The product has provisions for Ethernet, USB and RS-232 communications capability for downloadable selection and to upload data. Other features include automatic set up, a multi-language display and user friendly programming and diagnostics. More on the product. V.I.C.'s New Hydrogen Leak Tester SN-4455
Vacuum Instrument Corp. a world-leading manufacturer in the leak detection industry, develops a new series of Hydrogen gas leak detectors. The hand-held battery- operated Hydrogen sniffer leak detector is an
excellent complement to the V.I.C. leak detection product line, and ensures one-stop shopping for all our customers' leak detection equipment requirements. Its unique capabilities makes it easy to quickly and accurately detect leaks in the smallest of spaces.More on the product More on H2 testing
V.I.C.’s Helium Recovery product line features a group of high efficiency gas recycling systems that significantly reduce operating costs associated with Helium leak testing. Our wide choice of standard models and custom manufactured products provides the flexibility to quickly meet varying capacity requirements while reducing tracer gas operating costs. In order to provide complete peace of mind, V.I.C. offers truly complete leak-test solutions from product preparation to gas recycling, and everything else that you may need to make your production line as efficient as possible. More Details
Recalibration Services for CGLs / V.I.C. Offers a Variety of Calibrated Gas Leaks
We offer a full recalibration service for calibrated gas leaks manufactured by V.I.C. and other leak standard suppliers from our new state-of-the-art calibration laboratory located in our New York headquarters. Services include recalibrating and recharging with replacement of the precision element if breakage or clogging occurs, along with full N.I.S.T. recertification. Certificates of N.I.S.T. traceability are provided with each leak standard documenting the accuracy, and calibration parameters. This information is perfect for those companies with ISO quality systems procedures. More Details
-SEMICON West 2011 July 12 ~ 14, booth no. 6360, Moscone Convention Center, San Francisco, California.
-Assembly & Automation Technology Expo 2011 September 20 ~ 22, booth no. 1342, McCormick Place North, Chicago, Illinois.
Please feel free to stop by our booth to discuss all of your leak detection applications and requirements.
V.I.C. manufactures, services and supports everything from industry-standard air, helium, and high-sensitivity leak detection units and the detectors that drive them to complete turnkey leak-test solutions including gas handling and recovery systems.
Everything you need from one reliable source, worldwide, for more than 50 years. More
Questions? Contact us at http://www.vicleakdetection.com/contact.htm or call 631-737-0900 x113.
